MIL-DTL-83517/7A
INCHES
MM
INCHES
MM
NOTES:
.001
.03
.085
2.16
1. Dimensions are in inches.
.002
.05
.120
3.05
2. Metric equivalents are given for information only.
.003
.08
.125
3.18
3. All undimensioned pictorial configurations are for
.004
.10
.250
6.35
reference purposes only.
.005
.13
.390
9.91
.010
.25
.4375
11.11
.050
1.27
.438
11.13
.068
1.73
.528
13.41
.072
1.83
.570
14.48
FIGURE 1. Series SMA, pin contact, surface launch, receptacle Continued.
ENGINEERING PARAMETERS
Nominal impedance: 50 ohms.
Voltage rating: 335 V rms maximum at sea level.
150 V rms maximum at 70,000 feet.
Frequency range: 0 to 12.4 GHz.
Temperature rating: -65º to 105ºC.
REQUIREMENTS
Design and construction: See figure 1, table I and MIL-STD-348.
Force to engage and disengage:
Torque 2 inch-pounds maximum.
Longitudinal force Not applicable.
Coupling proof torque: 15 inch-pounds minimum.
Inspection note: For each test of threaded coupling connector where the test is performed on mated
pairs, the pairs shall be torqued to 7 to 10 inch-pounds.
TABLE I. PIN and characteristics.
PIN
Connector
Characteristics
M83517/7-
figure no.
31001
1
Strip transmission line surface launch, receptacle for .125 inch
(3.18 mm) strip transmission line.
31002
1
Strip transmission line surface launch, receptacle for .250 inch
(6.35 mm) strip transmission line.
2
