MIL-DTL-83723/84F

Shell

EE

FF

JJ

size

8

.605

.635

.596

.590

10

.730

.760

.721

.715

12

.917

.947

.908

.902

14

.980

1.010

.971

.965

16

1.105

1.135

1.096

1.090

18

1.229

1.260

1.220

1.214

20

1.354

1.385

1.345

1.339

22

1.479

1.510

1.470

1.464

24

1.604

1.635

1.595

1.589

FIGURE 3. Dimensions and configurations - Continued.

11
