MIL-DTL-83723/84F
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified, tolerances are ± .005 (0.13 mm) for three place decimals and
± .01 (0.25 mm) for two place decimals and ±1° for all angles.
4. Coupling indicator line shall be color coded red.
5. Rear accessory interchangeability dimensions shall be in accordance with MIL-DTL-83723.
6. Shell size 8 will not mate with MIL-DTL-26500 connectors.
7. Phantomed configuration optional.
8. See table I for contact cavities requiring this dimension.
9. The centerline of indicated projection must be located on vertical centerline ± 2°.
FIGURE 3. Dimensions and configurations - Continued.
REQUIREMENTS:
Dimensions and configurations: See figures 1 and 3 for classes A, G, K, M, R, T, W and Z.
See figures 2 and 3 for classes N and S.
This connector mates with MIL-DTL-83723/87, MIL-DTL-83723/92, MIL-DTL-83723/96 and
MIL-C-83723/98.
Insert arrangements and polarizing positions: See MIL-STD-1554 and table I.
TABLE I. Insert arrangements requiring reduced diameter for lead-in
chamfers on outer row of contact cavities as indicated.
Shell size
Insert arrangements
Contact cavities
8
03, 98
1, 2, 3
10
06
1, 2, 3, 4, 5, 6
O-ring: See MIL-DTL-83723.
Part or Identifying Number (PIN) example:
M83723/
84
W
22
55
N
Military designation
Specification sheet number
Class
Shell size
Insert arrangement
Polarizing position
12
