MIL-DTL-83723/84F
Shell size
A thread
B
D
F
8
.562-24 UNEF-2A
.394
.290
.562
10
.688-24 UNEF-2A
.515
.388
.696
12
.875-20 UNEF-2A
.685
.558
.875
14
.938-20 UNEF-2A
.754
.627
.936
16
1.062-18 UNEF-2A
.881
.772
1.062
18
1.188-18 UNEF-2A
.987
.860
1.187
20
1.312-18 UNEF-2A
1.112
.985
1.312
22
1.438-18 UNEF-2A
1.237
1.110
1.437
24
1.562-18 UNEF-2A
1.362
1.235
1.562
Shell size
C
G
M thread
8
.418
.625-25 UN-2A
.413
10
.535
.750-20 UNEF-2A
.530
12
.705
.938-20 UNEF-2A
.700
14
.774
1.000-20 UNEF-2A
.137
.769
.097
16
.901
1.125-18 UNEF-2A
.896
18
1.007
1.250-18 UNEF-2A
1.002
20
1.132
1.375-18 UNEF-2A
1.127
22
1.257
.148
1.500-18 UNEF-2A
1.252
.128
24
1.382
.168
1.625-18 UNEF-2A
1.377
.128
FIGURE 3. Dimensions and configurations.
