INCH-POUND
MIL-DTL-83723/97C
21 May 2010
SUPERSEDING
MIL-C-83723/97B
24 April 1992
DETAIL SPECIFICATION SHEET
CONNECTORS, ELECTRICAL, (CIRCULAR, ENVIRONMENT RESISTING),
PLUG, (THREADED COUPLING, SELF-LOCKING, R.F.I. GROUNDING, CRIMP
SOCKET CONTACTS), (SERIES III, CLASSES N AND S FIREWALL)
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification sheet and MIL-DTL-83723.
1.280 MAX
.510
SEE "Y"
SEE NOTE 4
.500
.235 THD START
.215 (SEE NOTE 2)
.250 MIN THD
.068
ENG'T LENGTH
.048
.775 MAX
A COUPLING THD
(REF)
COUPLING
(SEE NOTE 2)
A
RING
.007 R
.061
MAX
.035
90°
K DIA
B DIA MAX
H DIA MIN
J
R
MIN DIA
INSERT
SHELL
30°
SEE
NOTE 3
C
.160
.010
KNURL
MARKING-LOCATION
OPTIONAL
FIGURE 1. Dimensions and configurations.
AMSC N/A
FSC 5935
