MIL-DTL-83723/97C
.377
.363
#20 .054 DIA
.309
FRONT OF
#16 .076 DIA
.051 .263
CONTACT
#12 .107 DIA
GROUND SPRING
.035
FULLY MATED
INDICATOR
.096
#20
DIA
.092
L DIA
.118
#20
DIA
MIN
.114
.150
.125 MIN
#16
DIA
.146
KEY LENGTH
DETAIL A
.210
#12 .206 DIA
.330
DETAIL R
Connector dimensions.
Shell
A
B
C
H
J
K
L
M
N
size
Thread
UNEF-2B
8
.562-24
.290
.025
.294
.405
.575
.425
.967
12
.396
10
.688-24
.388
.031
.428
.526
.707
.546
1.093
15
.517
12
.875-20
.558
.031
.598
.696
.895
.711
1.170
21
.687
14
.938-20
.627
.031
.667
.765
.957
.785
1.310
24
.756
16
1.062-18
.772
.031
.794
.892
1.084
.912
1.500
30
. 883
18
1.188-18
.860
.031
.900
.998
1.209
1.018
1.562
33
.989
20
1.312-18
.985
.031
1.025
1.123
1.334
1.143
1.710
36
1.114
22
1.438-18
1.110
.031
1.150
1.248
1.459
1.268
1.812
39
1.239
24
1.562-18
1.235
.031
1.275
1.373
1.584
1.393
1.948
42
1.364
FIGURE 1. Dimensions and configurations Continued.
3
