MIL-DTL-9177C
TABLE I. Qualification inspection.
Inspection
Requirement
Test method paragraph
paragraph
Group I (14 sample units)
Visual and mechanical inspection 1/
4.6.1
Contact mating
4.6.2
Contact resistance
3.6.2
4.6.3
Insulation resistance
3.6.3
4.6.4
Dielectric withstanding voltage
3.6.4
4.6.5
Insertion and withdrawal forces
3.6.5
4.6.6
Electromagnetic coupling (when specified)
4.6.7
Dielectric coupling (when specified)
4.6.8
Group II (6 sample units)
Thermal shock
4.6.9
Moisture resistance
4.6.10
Vibration
4.6.11
Shock (specified pulse)
4.6.12
Insulation resistance
Dielectric withstanding voltage
Salt spray (corrosion)
4.6.13
Torque (when specified)
4.6.14
Controlled drop (when specified)
4.6.15
Stack assembly (when specified)
4.6.16
Static load (when specified)
4.6.17
Shell impact
4.6.18
Group III (6 sample units)
Thermal shock
3.6.8
Contact spring pressure (when specified)
Spring life (when specified)
4.6.20
Frame strength (when specified)
4.6.21
Spring attachment clip life (when specified)
4.6.22
Cable retention (when specified)
4.6.23
3.6.22
Ant-rotation detents (when specified)
4.6.23.1
3.6.22.1
Group IV (2 sample units)
RFI shielding (when specified)
3.6.22.2
1/ Marking will be considered defective only if it is illegible at the completion of the required tests.
4.5.1.2 Group A inspection. Group A inspection shall consist of visual and mechanical inspection (see
4.6.1).
4.5.1.2.1 Rejected lots (group A inspection). If an inspection lot is rejected, the contractor may rework it
to correct the defects, or screen out the defective units, and resubmit for reinspection. Resubmitted lots
shall be inspected using tightened inspection and shall not thereafter be tendered for acceptance unless
the former rejection or requirement of correction is disclosed. Such lots shall be separate from new lots,
and shall be clearly identified as reinspected lots.
