MIL-PRF-39012/24D
Group qualification: See table II.
TABLE II. Group qualification.
Submission and qualification of
Qualifies the following
Group
any of the following connectors
connectors
I
M39012/24-X001
M39012/24-X001
M39012/24-X002
M39012/24-X002
Cross reference: See table III.
TABLE III. Cross reference of PINs.
PIN
Substitute for type 1/
designation
M39012/24-0001
UG-911/U
M39012/24-0002
UG-912/U
1/ The superseded PIN or the type designation
is for cross reference only. The PIN M39012/
24-XXXX shall be used in all cases for marking and
identifying the connector.
ENGINEERING DATA:
Nominal impedance: 50 ohms.
Frequency range: 0 to 4 GHz.
Voltage rating: 500 volts rms maximum working voltage at sea level. 125 volts rms maximum at
70,000 feet (4.437 kPa).
Temperature rating: -65°C to +165°C.
REQUIREMENTS:
Design and construction: See figure 1.
Center contacts: 4 pounds (17.8 N), minimum axial force.
4 inch-ounces (0.03 Nm), minimum radial torque.
Force to engage and disengage:
Longitudinal force 3 pounds (13.34 N), maximum.
Torque 2.5 inch-pounds (0.28 Nm), maximum.
Coupling mechanism retention force: Not applicable.
4
