MIL-PRF-39012/29H
Ferrule
Crimp die or
A
B
Basic crimp
Dash
number
positioner
tool 2/
± 0.003 ± 0.003
number
1/
M22520/5
05, 41
X501
Closure B or
29-50
0.212
0.175
X502
9 Closure A
M22520/5-01
X503
29-51
0.250
0.220
05, 11, 57
Closure A or
X504
29-52
0.245
0.206
19 closure B
1/ Contact numbers and ferrule numbers are for identification only.
2/ Class 2 tool may be used by OEM (see MIL-DTL-22520).
FIGURE 3. Contact and ferrule dimensions for category D only.
6
