MIL-PRF-39012/34B
TABLE I. Dash number and overall dimensions.
Inches-millimeters 1/
Maximum
Dash No.
Dim
panel
thickness
Minimum
Maximum
0001
A
1.343 (34.11)
B
.684 (17.37)
.690 (17.53)
.125 (3.18)
C
.769 (19.53)
.893 (22.68)
0002
A
1.328 (33.73)
B
.630 (16.00)
.650 (16.51)
.250 (6.35)
C
.626 (15.90)
.750 (19.05)
1/ Millimeters are in parentheses.
TABLE II. Group qualification.
Group
Submission and qualification of
Qualifies the following
any of the following connectors
connectors
I
0001
0001
0002
0002
ENGINEERING DATA
Nominal impedance: 50 ohms.
Frequency range: 0 to 11,000 MHz.
Voltage rating: 500 volts rms maximum working voltage at sea level, 125 volts rms maximum at 70,000
feet.
Temperature rating: -65°C to +165°C.
REQUIREMENTS
Dimensions and configuration: See figure 1.
Force to engage and disengage:
Longitudinal force Not applicable.
Torque 2 inch-pounds maximum.
Coupling proof torque: Not applicable.
Inspection conditions:
Coupling torque 4 to 6 inch-pounds.
Mating characteristics: See figure 2 for dimensions.
Center contact (female)
Oversize test pin - .057 diameter minimum (non-closed entry contacts only).
Insertion depth - .125 minimum.
Number of insertions 1.
Insertion force test Steel test pin dia .054 minimum.
Test pin finish 16 microinches.
Insertion force 2 lbs maximum.
4
