MIL-PRF-39012/4F
TABLE I. Dash numbers, cross-reference, and dimensions.
Inches (millimeters) 2/
Dash number
Type
Dimension
1/
Min
Max
Bulkhead
A
--
1.750 (44.45)
0001 3/
(front mounted
B
--
.885 (22.48)
7001 3/
hermetic sealed)
C
1.125 (25.40)
1.250 (31.75)
D
.702 (17.83)
.721 (18.08)
Flange
A
1.062 (26.97)
1.156 (26.36)
0002 3/
(rear mounted)
B
.620 (15.65)
.670 (17.02)
7002 3/
C
.721 (18.31)
.751 (19.08)
D
.075 (1.91)
.085 (2.16)
Bulkhead
A
--
1.343 (34.11)
0003 3/
(rear mounted)
B
.850 (21.59)
.900 (22.86)
7003 3/
C
.912 (23.16)
.940 (23.88)
1/ For cross-reference of dash number to superseded Part or Identifying Number (PIN) or type
designation, see table III.
2/ Dimensions are in inches. Metric equivalents are given for information only.
3/ These connectors have captivated center contacts.
ENGINEERING DATA:
Nominal impedance: 50 ohms.
Frequency range: 0 to 11 GHz.
Voltage rating
1,000 volts rms maximum working voltage at sea level.
250 volts rms maximum at 70,000 feet (4.437 kPa).
Temperature rating: -65°C to +165°C.
REQUIREMENTS:
Design and configuration: See figure 1.
Force to engage and disengage:
Longitudinal force: Not applicable.
Torque: 6 inch-pounds (.68 Nm) maximum.
Coupling proof torque: Not applicable.
Inspection conditions: Coupling torque: 6 to 10 inch-pounds (.68 to 1.13 Nm).
3
