MIL-PRF-39012/4F
Insertion loss: Not applicable.
Part or Identifying Number (PIN): M39012/04- (dash number from table I).
CAUTION: THE "7000" SERIES OF DASH NUMBERS ALLOW FOR A NICKEL PLATED
CONNECTOR BODY. A NICKEL PLATED BODY IS NOT FOR USE IN APPLICATIONS
WHERE PASSIVE INTERMODULATION GENERATION (PIM) MAY BE A CONCERN
(https://amphenolrf.com/simple/PIM%20Paper.pdf). Silver is the preferred plating option.
Group qualification: See table II.
Cross-reference information: See table III.
TABLE II. Group qualification. 1/, 2/
Submission and qualification of
Qualifies the following
Group
any of the following connectors
connectors
I
M39012/04-X001
M39012/04-X001
II
M39012/04-X002
M39012/04-X002
III
M39012/04-X003
M39012/04-X003
1/ If a connector manufacturer produces a connector which meets all the requirements for two or
more connector PIN (within the same series), the manufacturer may receive qualification approval
for two or more connector PIN by qualifying the one connector. It is not necessary that such
connectors be in the same group. Each connector, however, must be marked with its own
appropriate PIN. For group qualification, the connectors must be of similar design.
2/ Connectors of the same body material and finish may only qualify connectors of the same body
material and finish.
TABLE III. Cross-reference of PIN's.
Preferred PIN
Substitute for PIN
or type designation 1/
M39012/04-0001
MS90531-680A
M39012/04-0002
UG-58/U
M39012/04-0003
--
1/ The superseded PIN or the type designation is for cross-reference only. Where a superseded PIN or
type designation is not given, none was assigned or will be assigned. The PIN M39012/04-XXXX shall
be used in all cases for marking and identifying the connector.
Changes from previous issue. The margins of this specification are marked with vertical lines to indicate
where changes from the previous issue were made. This was done as a convenience only and the
Government assumes no liability whatsoever for any inaccuracies in these notations. Bidders and
contractors are cautioned to evaluate the requirements of this document based on the entire content
irrespective of the marginal notations and relationship to the last previous issue.
6
