MIL-PRF-39012/40J
TABLE I. Dash numbers, cross-reference, and dimensions Continued.
Applicable cable 2/
Inches *
Dash No. 1/
M17/
Dimensions
(millimeters)
Minimum
Maximum
CATEGORY C FIELD REPLACEABLE (MIL-C-22520/5 CRIMP TOOL)
SEE NOTE NEXT TO APPLICABLE CABLE GROUP FOR CRIMP DIE 3/ 7/
X014
Cable group VIII 8/
2-RG6 4/
180-00001 4/
112-RG304 5/
X015
Cable group XA 9/
65-RG165 5/ 6/
X016
Cable group XB 9/
A
2.030 (51.56)
127-RG393 5/
C
.915 (23.24)
1.045 (26.54)
86-00001 6/
X017
Cable group XD 9/
77-RG216 4/ 8/
191-00001 4/
X018
078-RG217 4/ 8/
X021
Cable group XC 9/
62-RG144 4/ 5/ 6/
X022
Cable group IX 9/
92-RG115 5/ 6/
CATEGORY D FIELD REPLACEABLE DEFINED PIECE PARTS 3/ 7/ 10/ 11/
X501
Cable group XB
127-RG393 5/
86-00001 6/
X502
Cable group XA
A
2.030 (51.56)
C
1.045 (26.54)
65-RG165 5/
X503
Cable group VIB
128-RG400 5/
60-RG142 6/
See notes at end of table.
