MIL-PRF-39012/55H
TABLE IV. Group qualification and retention testing Continued.
Group
Submission and qualification of
Qualifies the following connectors
any of the following connectors
3/
1/ 2/
M39012/55-*025
IV
M39012/55-*028
M39012/55-*026
M39012/55-*027
M39012/55-*028
M39012/55-*029
V
M39012/55-*502
M39012/55-*502
1/ Individual connectors other than listed in the middle column, are self qualifying. Retention of qualification of
connectors of equal or lower frequency is granted by similarity.
2/ Qualification of connectors qualifies connectors of the same material only.
3/ Connectors qualified with safety wire holes automatically qualifies connectors without safety wire
holes.
* Denotes material.
NOTES:
1. For qualification retention, where more than one part is listed in a group in the middle column, data
may be supplied on any of those parts in order to retain qualification for those parts in the
corresponding right hand column. The part does not necessarily have to be the part initially
qualified. This note does not apply if there is only one port listed in the middle column.
2. If a connector manufacturer produces a connector which meets all the requirements for two or
more connector PINs (within the same series), the manufacturer may receive qualification
approval for two or more connector PINs by qualifying the one connector. It is not
necessary that such connectors be in the same group. Each connector, however, must be marked
with its own appropriate PIN. For group qualification, the connectors must be of similar
design.
10
