MIL-PRF-39012/55H
TABLE II. Voltage rating.
Voltage max. (at sea level)
Voltage max. (V rms) at 70,000
Cables
(V rms)
feet (4.437 kPa)
Cable group I
170
45
Cable group II, IIa, III, IV
250
65
Cable group VI, VIa, VIb
335
85
Crimp
Color band
Color band
Dash
Contact no.
A
Basic crimp
Crimp die or
tensile
1/
tool 2/
no.
±.001
positioner
minimum
3502
55-10
.041
M22520/1-01
Solder or
6 pounds
Red
Silver
4502
M22520/1-15
Crimp die or
Dash
Ferrule no.
A
B
Basic crimp
positioner
1/
tool 2/
no.
±.003
±.003
M22520/5-
-05, -11, -57
3502
55-50
.250
.220
M22520/5-01
Closure A or
4502
-19 Closure B
1/ Contact numbers and ferrule numbers are for identification only.
2/ Class 2 tool may be used by OEM (see MIL-DTL-22520).
FIGURE 3. Contact and ferrule dimensions for category D only.
