MIL-PRF-39012/75C
RF high potential withstanding voltage:
Voltage and frequency: Tested at a frequency from 5 to 7.5 MHz.
Leakage current: Not applicable.
Cable group
Volts, rms min.
I
500
II, IIa and
700
M17/95-RG180
Cable retention force: The cable retention force shall be as specified in table III.
TABLE III. Cable retention force. 1/ 2/
Pounds, min. (N)
Cable dielectric
Non-crimp
Crimp
outer diameter
Single braid
Single braid
Center contact
Center contact
Captive
Captive
Inches, max. (mm)
.036 (0.91)
13 (57.83)
13 (57.83)
.066 (1.68)
25 (111.20)
25 (111.20)
1/ Dimensions are in inches.
2/ Metric equivalents are given for information only.
Coupling mechanism retention force: 35 pounds, minimum.
RF leakage: -60 dB minimum, tested at frequency between 2 and 3 GHz. This requirement may be
met by qualifying the straight connector versions for the same cable under MIL-PRF-39012/73.
RF insertion loss: .5 dB maximum tested at 4 GHz.
PIN: M39012/75 (dash number in table I or IV as applicable).
Group qualification: See table V.
Cross reference of PIN: See table VI.
8
