MIL-PRF-39012/81G
TABLE IV. Group qualification and retention testing Continued. 1/
1/ If a connector manufacturer produces a connector which meets all the requirements for two or more
connector PINs (within the same series), the manufacturer may receive qualification approval for two
or more connector PINs by qualifying the one connector. It is not necessary that such connectors be
in the same group. Each connector, however, must be marked with its own appropriate PIN. For
group qualification, the connectors must be of similar design.
2/ For qualification retention, where more than one part is listed in a group in this column, data may be
supplied on any of those parts in order to retain qualification for those parts in the corresponding
right-hand column. The part does not necessarily have to be the part initially qualified. Qualification of
connectors qualifies connectors of the same body material and finish only.
* Denotes body material and connector requirement.
TABLE V. Category B Non-field replaceable (special tools may be required). 1/
NOT FOR ARMY, NAVY, OR AIR FORCE USE. FOR OEM USE
M39012/81B 2/
Applicable cable 3/
Dimension A
Maximum 6/ 7/
3001 4/
M17/133-RG405 *
.850
3002 4/
M17/130-RG402 *
(21.59 mm)
M17/133-RG405 *
3003 5/
4003 5/
3004 5/
M17/130-RG402 *
4004 5/
1/ Dimension B shown on figure 1 is not applicable to these connectors.
2/ All corrosion resistant steel bodied connectors which are designed to be assembled to the
outer conductor using solder shall be gold plated in accordance with ASTM B488, type II,
code C, class 1.27.
3/ MIL-DTL-17 cables are specified by the basic number. The latest version of each cable shall
be applicable.
4/ In active for new design.
5/ These connectors have captivated center contacts.
6/ Dimensions are in inches.
7/ Metric equivalents are given for information only.
* Cable to be used when performing tests requiring cable. All cable PIN's on this
specification sheet shall accommodate this connector.
11
