MIL-PRF-39012/81G
Corona level:
Altitude: 70,000 feet (4.437 kPa).
Cable group
Volts, min.
M17/133-RG405 *
250
M17/130-RG402 *
375
* Values apply to all cable PINs on these specification sheets even if not listed.
RF high potential withstanding voltage:
Voltage and frequency: Tested at a frequency from 5 to 7.5 MHz.
Leakage current: Not applicable.
Cable group
Volts, min.
M17/133-RG405 *
670
M17/130-RG402 *
1,000
* Values apply to all cable PINs on these specification sheets even if not listed.
Cable retention force: The cable retention force shall be as specified in table III.
TABLE III. Cable retention force.
Cable *
Pounds, minimum
Torque 1/
(N)
Inch-ounces (Nm)
M17/133-RG405
30 (133.45 N)
16 (.11 Nm)
M17/130-RG402
60 (266.90 N)
55 (.39 Nm)
* Values apply to all cable PINs on the below specification sheets even if not listed.
1/ Torque to be applied 4 inches maximum from the end of the connector. Reverse bend not
applicable.
Coupling mechanism retention force: Not applicable.
RF leakage: -90 dB minimum, tested at frequency between 2 and 3 GHz..
RF insertion loss: .03 √ F (GHz) dB maximum tested at 9 to 12.4 GHz.
8
