MIL-PRF-55339/24B
Inches
mm
Inches
mm
.075
1.91
.630
16.00
.085
2.16
.641
16.28
Reference
Series
Contact
.120
3.05
.671
17.04
A
BNC
Pin
.130
3.30
.710
18.03
B
N
Socket
.218
5.54
.713
18.11
.354
8.99
.723
18.36
.364
9.25
.985
25.02
.492
12.50
1.005
25.53
.500
12.70
1.500
38.10
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. All undimensioned pictorial representations are for reference purposes only.
4. Interface dimensions shall be in accordance with MIL-STD-348, series BNC pin contact and series
N socket contact.
FIGURE 1. General configuration - Continued.
DESIGN AND CONSTRUCTION
General configuration: See figure 1.
Impedance: 50 ohms, nom.
Working voltage: Sea level 500 V rms.
70,000 feet (4.437 kPa) 125 V rms.
Frequency range: 0 to 4 GHz.
Temperature range: -65º to +165ºC.
PERFORMANCE (installation torque of 6 to 10 in. lb (0.68 to 1.13 Nm), series N)
Dimensions: See figure 1 and MIL-STD-348.
Center contact retention:
Series BNC
Series N
Axial force (lb. min)
6 (26.7 N)
6 (26.7 N)
Torque (in. oz, min)
N/A
N/A
Series N
Force to engage and disengage:
Series BNC
Longitudinal force (lb. max)
3.0 (13.3 N)
N/A
Torque (in. lb, max)
2.5 (0.34 Nm) 6.0 (0.68 Nm)
2
