MIL-PRF-55339/24B
Contact resistance (milliohms, max):
Initial
After
Contact
Center
1.0
1.5
Outer
1.5
N/A
Outer (-7001)
3.0
N/A
Vibration, high frequency: Interruptions 1 µs, max.
Shock: Test condition I.
Thermal shock: Test condition C.
Moisture resistance: 200 megohms, min.
Corona level: Voltage 375 V, min.
Altitude - 70,000 feet (4.437 kPa), min.
RF high potential withstanding voltage: RF voltage 1,000 V rms. min.
Frequency 5 MHz, min.
Salt spray (corrosion): Applicable.
Coupling mechanism retention force: Not applicable.
Part or Identifying Number (PIN): M55339/24-00335.
PIN: M55339/24-70001. CAUTION: THIS PART HAS A NICKEL PLATED BODY AND IS NOT FOR
USE IN APPLICATIONS WHERE PASSIVE INTERMODULATION GENERATION (PIM) MAY BE A
CONCERN.
TABLE I. Cross reference of PIN's.
PIN
Superseded PIN or type designation 1/
M55339/24-00335
REB49103
UG-335A/U
1/ The superseded PIN or the type designation is for cross reference only. Where a
superseded PIN or type designation is not given, none was assigned or will be
assigned. The PIN M55339/24-00335 shall be used in all cases for marking and
identifying the adapter.
Marginal notations is not used in this revision to identify changes with respect to the previous issue due to
the extent of the changes.
Referenced documents. In addition to MIL-PRF-55339, this document references the following:
MIL-STD-348
