INCH-POUND
MIL-PRF-55339C
3 August 2005
SUPERSEDING
MIL-PRF-55339B
1 April 1996
PERFORMANCE SPECIFICATION
ADAPTERS, CONNECTORS, COAXIAL, RADIO FREQUENCY,
(BETWEEN SERIES AND WITHIN SERIES),
GENERAL SPECIFICATION FOR
This specification is approved for use by all Departments and
Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification covers the performance requirements and tests for between series
and within series, radio frequency (RF), coaxial connector adapters.
1.2 Classification. Adapters consist of the following classes with the Part Identifying Number (PIN),
as specified (see 3.1).
a. Class 1 A class 1 adapter is an adapter which is intended to provide superior RF
performance at specified frequencies, and for which all RF characteristics are completely
defined.
b. Class 2 A class 2 adapter is intended to provide mechanical connection within an RF circuit
providing specified RF performance.
1.2.1 PIN. The PIN consists of the letter "M" followed by the basic specification sheet number. The
first digit in the dash number designates the material and finish of the adapter body (shell); i.e., "0" for
silver plated brass, "3" for passivated corrosion-resistant steel, "4" for gold plated copper beryllium, "6"
to be used between series SMA and other series (SMA body to be corrosion resistant steel and the
other series to be brass), or "7" for nickel plated brass. Succeeding digits will be assigned to
designate the former `UG' number or a nonsignificant number, as applicable.
Example:
01
-
XXXXX
M55339/
General specification
Dash number from specification sheet
Specification sheet
Comments, suggestions, or questions on this document should be addressed to: Commander,
Defense Supply Center Columbus, Attn: VAI, P.O. Box 3990, Columbus, Ohio, 43218-3990 or
emailed to RFConnectors@dscc.dla.mil. Since contact information can change, you may want
to verify the currency of this address information using the ASSIST Online database at
AMSC N/A
FSC 5935
