MIL-DTL-12883/44D
REQUIREMENTS:
Dimensions and configurations: See figures 1, 2, 3, and table I.
Insulator: Diallyl phthalate, in accordance with ASTM D5948, type SDG-F, or any glass filled
thermoplastic material in accordance with ASTM D5204.
Color: Material color shall be optional providing that the color provides a contrasting background for
the blue sealing grommet or blue color bands indicating rear release contacts.
Grommet: Silicon rubber.
Mounting hardware: Corrosion resistant steel or steel with cadmium/chromate finish.
Electrical
Test gauge: A mating relay in accordance with table I shall be used as a test gauge or mating
connector.
Insulation resistance: 1,000 megohms minimum.
Dielectric withstanding voltage:
Sea level: Test voltage: 1,000 V rms.
High altitude, 80,000 feet (24,384 meters): Test voltage: 500 V rms.
Contact resistance: In accordance with MIL-C-39029/101 (see table I).
TABLE I. Dash numbers and configurations.
Number
Contact
Polarization
Contact
Dash
Mating
designation
of
relay
number/socket
(see figure 1
size
M39029/101
contacts
detail A)
mating
configuration
MIL-PRF-83536
1/
end
wire
barrel
/5-019, -022, -014,
None
-01
20
20
14
-553
/6-003, -006, -011, -014,
019, -022, -029, -032
-02
20
20
16
-553
/7-022
I
-03
20
20
16
-553
TBA
II
-04
20
20
16
-553
TBA
III
1/ Reference MIL-PRF-83536 for supersession data on MIL-PRF-6106 relays.
