MIL-DTL-12883/44D
PIN: The PIN shall be marked on the socket body as shown in the example (see figure 1). The PIN
shall consist of the basic number of this specification sheet and the dash number from table I.
Example:
*
M12883/44
-01
S
Basic document number
Dash number
Modifier S shall be used in the
PIN only when ordering sockets
furnished with corrosion resistant
steel hardware with no finish.
* For future acquisition of these sockets as of the effective date of revision B, 20 December 1989,
parts identified with an "S" modifier shall be corrosion resisting steel (CRS), and parts without an "S"
modifier shall be cadmium chromate finish. No mixing of hardware types shall be permitted.
Ordering data: Sockets without contacts may be ordered when so indicated in the ordering data (see
MIL-DTL-12883). This applies only to original equipment manufacturers (OEMs) and subcontractors.
All direct shipments to the government shall include all applicable contacts and mounting hardware.
The PIN to be marked on the socket shall be as shown in the PIN example (see figure 1 and table I).
Revision letters are not used to denote changes due to the extensiveness of the changes.
Superseded manufacturer
Active
PIN
Government
PIN
CAGE
CAGE
58982
99699
M12883/44-01
RSE120151
SE405-1020
M12883/44-02
RSE120153 SEL405-1021
M12883/44-03
RSE120155 SEL405-1022
M12883/44-04
RSE120157 SEL405-1023
9
