MIL-DTL-12883/44D
TABLE III. Torque requirements (installed in panel conditions).
Torque
Thread size
Testing
Installation
Inch-pounds Newton-meter
Inch-pounds Newton-meter
4 +1
0.90
.112-40
8
0.45 + .11
+ .11
+1
-0
-0
15 +1
2.26
.164-32
20
1.70 + .11
+ .11
+1
-0
-0
Socket, contact tools shall be in accordance with table IV.
TABLE IV. Contact tools.
Nomenclature
Part or Identifying Number (PIN)
Crimp tool
M22520/7-01
Positioner
M22520/7-12
Insertion and removal tool
M81969/16-01
Weight: The socket, hardware, and electrical contacts shall have a maximum weight of .055 pounds
(25 grams).
Mounting hardware: The mounting hardware shall allow mounting the socket above, or below the
panel or chassis (see figure 2), and shall allow mounting and securing the relay to the socket without
disturbing the mounted socket or access to the wiring side of the socket. The hardware shall provide
the nominal .197 inch (5.00 mm) spacing between socket surface and relay mounting flange,
regardless or mounting configuration.
Mounting hardware shall be supplied with the relay socket and shall consist of the following:
Self locking nuts .112-40 (6 each) (.206 max dia x .176 max height).
Flat washers .112 (6 each) (.206 max O.D. x .021 max thickness).
Self locking nuts .164-32 (3 each) (.290 max dia x .190 max height).
Flat washers .164 (3 each) (.290 max O.D. x .019 max thickness).
8
