MIL-DTL-12883/45D
PIN: The PIN shall be marked on the socket body as shown in the example (see figure 1). The PIN shall
consist of the basic number of this specification sheet and the dash number from table I.
Example:
*
M12883/45
-01
S
Basic document number
Dash number
Modifier S shall be used in the
PIN only when ordering sockets
furnished with corrosion resistant
steel hardware with no finish.
* For future acquisition of these sockets as of the effective date of revision B, 20 December 1989, parts
identified with an "S" modifier shall be corrosion resisting steel (CRS), and parts without an "S" modifier
shall be cadmium chromate finish. No mixing of hardware types shall be permitted.
Ordering data: Sockets without contacts may be ordered when so indicated in the ordering data (see
MIL-DTL-12883). This applies only to original equipment manufacturers (OEMs) and subcontractors. All
direct shipments to the government shall include all applicable contacts and mounting hardware. The PIN
to be marked on the socket shall be as shown in the PIN example (see figure 1 and table I).
Revision letters are not used to denote changes due to the extensiveness of the changes.
TABLE VI. Supersession and cross reference.
Superseded manufacturer PIN
Active
Government
CAGE
CAGE
PIN
58982
99699
M12883/45-01
RSE120159
SE205-1010
M12883/45-02
RSE120161
SE205-1011
M12883/45-03
RSE120163
SE205-1012
M12883/45-04
RSE120165
TBD
M12883/45-05
RSE120167
TBD
M12883/45-06
RSE120169
TBD
8
