MIL-DTL-12883/46D
Environmental:
Temperature range: Operating temperature range -70ºC to +125 ºC.
Wire sealing: A resilient socket grommet is permanently bonded to the wire entry face of the socket
so as to provide moisture sealing capabilities, over the following range of finished wire:
Contact
Wire diameter
M39029/101-553
.040 min-.083 max (1.02 min-2.11 max mm)
M39029/101-554
.053 min-.103 max (1.35 min-.103 max mm)
Mechanical:
Contacts: Contact shall be in accordance with table I. Contacts shall be crimp removable type, rear
release and accept the following relay pins:
a. Size 16: .0610 through .0630 inch (1.55 through 1.60 mm).
b. Size 20: .039 through .041 inch (.099 through 1.04 mm).
Insertion and withdrawal force: The insertion and withdrawal forces shall be as specified in table II.
TABLE III. Insertion and withdrawal forces.
M12883/46
Condition
Test
-01
-02 through -04
19.1 lbf
21.4 lbf
Insertion force (max)
Initial
(85 newton)
(95.2 newton)
1.2 lbf
1.3 lbf
Withdrawal force (min)
(5.3 newton)
(5.78 newton)
After 10 insertions
23 lbf
25.8 lbf
Insertion force (max)
and withdrawals,
(102.3 newton)
(114.8 newton)
before vibration
.92 lbf
1.0 lbf
Withdrawal force (min)
(4.1 newton)
(4.45 newton)
23 lbf
25.8 lbf
Insertion force (max)
After vibration
(102.3 newton)
(114.8 newton)
.92 lbf
.99 lbf
Withdrawal force (min)
(4.1 newton)
(4.40 newton)
Durability: Shall be in accordance with MIL-DTL-12883.
Vibration (sinusoidal): In accordance with MIL-STD-202, method 204, test condition G.
a. Except that the frequency range shall be varied logarithmically between the limits of 10 Hz
and 3,000 Hz.
b. Except that the procedure of method of 201 of MIL-STD-202 may be applied during 10 Hz to
55 Hz band of the vibration frequency range.
Vibration (random): In accordance with MIL-STD-1344, method 2005, test condition V, letter G, with a
test duration of 15 minutes. The mating relay shall be used as the test gage.
