MIL-DTL-12883/46D
PIN: The PIN shall be marked on the socket body as shown in the example (see figure 3). The PIN
shall consist of the basic number of this specification sheet and the dash number from table I.
Example:
*
M12883/46
-01
S
Basic document number
Dash number (see table I)
Modifier S shall be used in the
PIN only when ordering sockets
furnished with corrosion resistant
steel hardware with no finish.
* For future acquisition of these sockets as of the effective date of revision B, 20 December 1989,
parts identified with an "S" modifier shall be corrosion resisting steel (CRS), and parts without an "S"
modifier shall be cadmium chromate finish. No mixing of hardware types shall be permitted.
Packaging: Hardware, socket insulator, and contacts shall be packaged in separate packages within a
common container.
Revision letters are not used to denote changes due to the extensiveness of the changes.
The Government PIN, specified in table VI, supersedes the following commercial PINs.
TABLE VI. Supersession and cross reference.
Superseded manufacturer PIN
Active
Government
PIN
CAGE
CAGE
99699
58982
M12883/46-01
RSE116747
SE310-1010
M12883/46-02
RSE116749
SEL-310-1011
M12883/46-03
RSE116751
SEL310-1012
M12883/46-04
RSE116753
SEL310-1013
8
