MIL-DTL-24308/36 Connectors, Electric, Rectangular, Miniature, Combination Insert Arrangement, Receptacle, Socket Contacts, Shell Size 4, Size 20 Signal Contacts and Size 8 Power and Shielded, Class G, M, N and D

1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20 - 21 - 22 - 23 - 24 - 25 - 26


MIL-DTL-24308/36
TABLE I. PIN and dash numbers - Continued.
Insert
PIN
arrangement
Size 8
Termination
Mounting
(see figure 1)
contact
type
configuration
(see figure5)
M24308/36-101
0.078
Straight
A
M24308/36-102
0.078
Straight
D
M24308/36-103
0.078
Right angle
B
M24308/36-104
0.078
Right angle
E
M24308/36-105
0.078
Right angle
C
M24308/36-106
0.078
Right angle
F
M24308/36-107
0.125
Straight
A
M24308/36-108
0.125
Straight
D
13W6
M24308/36-109
0.125
Right angle
B
M24308/36-110
0.125
Right angle
E
M24308/36-111
0.125
Right angle
C
M24308/36-112
0.125
Right angle
F
M24308/36-113
Shielded
Straight
A
M24308/36-114
Shielded
Straight
D
M24308/36-115
Shielded
Right angle
B
M24308/36-116
Shielded
Right angle
E
20
