MIL-DTL-24308/36
TABLE II. PIN and dash numbers - Continued.
Insert
PIN
arrangement
Size 8
Termination
Mounting
(see figure 1)
contact
type
configuration
(see figure 5)
M24308/36-401
0.078
Straight
A
M24308/36-402
0.078
Straight
D
M24308/36-403
0.078
Right angle
B
M24308/36-404
0.078
Right angle
E
M24308/36-405
0.078
Right angle
C
M24308/36-406
0.078
Right angle
F
M24308/36-407
0.125
Straight
A
M24308/36-408
0.125
Straight
D
25W3
M24308/36-409
0.125
Right angle
B
M24308/36-410
0.125
Right angle
E
M24308/36-411
0.125
Right angle
C
M24308/36-412
0.125
Right angle
F
M24308/36-413
Shielded Straight
A
M24308/36-414
Shielded Straight
D
M24308/36-415
Shielded Right angle
B
M24308/36-416
Shielded Right angle
E
23
