MIL-DTL-24308/36 Connectors, Electric, Rectangular, Miniature, Combination Insert Arrangement, Receptacle, Socket Contacts, Shell Size 4, Size 20 Signal Contacts and Size 8 Power and Shielded, Class G, M, N and D

1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20 - 21 - 22 - 23 - 24 - 25 - 26


MIL-DTL-24308/36
TABLE II. PIN and dash numbers - Continued.
Insert
PIN
arrangement
Size 8
Termination
Mounting
Configuration
(see figure 1)
contact
type
(see figure 5)
M24308/36-501
0.078
Straight
A
M24308/36-502
0.078
Straight
D
M24308/36-503
0.078
Right angle
B
M24308/36-504
0.078
Right angle
E
M24308/36-505
0.078
Right angle
C
M24308/36-506
0.078
Right angle
F
M24308/36-507
0.125
Straight
A
M24308/36-508
0.125
Straight
D
27W2
M24308/36-509
0.125
Right angle
B
M24308/36-510
0.125
Right angle
E
M24308/36-511
0.125
Right angle
C
M24308/36-512
0.125
Right angle
F
M24308/36-513
Shielded Straight
A
M24308/36-514
Shielded Straight
D
M24308/36-515
Shielded Right angle
B
M24308/36-516
Shielded Right angle
E
24
