MIL-DTL-25516F
1.2.1 Part or Identifying Number (PIN). The military PIN will consist of the letter "M" followed by the
basic specification sheet number and a sequentially assigned dash number which is used to designate the
polarity and a letter to designate the cable size as shown in the following example:
M25516/
01 - XX - XX
Basic specification
Specification sheet number
Polarity (see 1.2.2)
Cable size when applicable (see 1.2.3)
1.2.2 Polarity. The mating interface of connectors covered by this specification should be polarized as
specified on figure 1 (see 3.1). Where connector configuration includes minor variables such as mounting
features, solder terminations, etc. The first digit in the polarity dash number may be changed to show the
variation. Dash number for polarities should be as specified in table I.
