MIL-DTL-25955A
± 1°
D
E
B
A
± .001
± .001
Wire
Size
+ .000 / - .010
20
MIL-W-5086, type I
.035 (.889)
.040 (1.016)
180
.040 (1.016)
.102 (2.590)
22
NEMA HP3
24
.035 (.889)
.035 (.889)
60
.046(1.168)
.092 (2.337)
RG-179/U
NOTES:
1. Dimensions are in inches.
2. Tolerances are ±.002 inch (0.05 mm) except as noted.
3. Crimped contact shall be adaptable to a tool in accordance with figure 2. This figure is intended to
specify a tool for test and acceptance and not necessarily a final design.
FIGURE 4. Test crimp tool.
