MIL-DTL-2726/38D
SELECT PACKING ASSEMBLY TO SUIT CABLE DIAMETER
BUSHING
USE PACKING ASSEMBLY
CABLE DIA
"D" HOLE
Part or Identifying Number (PIN)
.400 - .440
.415
M2726/50-004-1
.440 - .520
.470
M2726/50-004-2
.520 - .560
.550
M2726/50-004-3
Inches
mm
.400
10.16
.415
10.54
.440
11.18
.470
11.94
.520
13.21
13.97
.550
.560
14.22
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified, tolerances are ± .016 (0.41mm) and ± .5° on angles.
FIGURE 2. Instruction sheet.
2
