MIL-DTL-28754/17D
REQUIREMENTS:
Dimensions and configuration: In accordance with figures 1 through 5.
Applicable connector block: In accordance with MIL-C-28754/16.
Applicable contact assembly: In accordance with MIL-C-28754/15.
Applicable cable clamp: See figure 2.
Applicable cover plate: See figure 3.
Applicable cable clamp screw: See figure 4.
Applicable cover plate screw: See figure 5.
Contact installing tool: See MIL-I-81969/2.
Contact removal tool: See MIL-I-81969/3.
Marking in accordance with MIL-C-28754, figure 1, and table I.
Military Part or Identifying Number (PIN):
M28754/17- (dash number from table I).
TABLE I. Dash numbers and characteristics.
Dash number
Connector
M28754/49
Cover plate
Housing
type
type
(see figure 3)
01
M28754/16-01
A
A
02
M28754/16-01
B
B
03
M28754/16-01
C
A
04
M28754/16-02
A
A
Individual piece part ordering PIN's:
Cable clamp (see figure 2) PIN:
MS14060
Cable clamp screw (see figure 4) PIN
MS14066
Cover plate (see figure 3) PIN:
MS14061
Cover plate screw (see figure 5) PIN:
MS14065
Supersession data: This specification includes the requirements of Navy (10001) drawing number
2826728.
Qualification testing: Perform the applicable tests as specified in MIL-C-28754 and the appendix thereto.
Extended qualifications: Qualifications of M28754/17-01, /17-02, /17-03, or /17-04 extends qualifications
to other products as specified in the appendix to MIL-C-28754.
