INCH-POUND
MIL-DTL-28804D
10 September 1998
SUPERSEDING
MIL-C-28804C
12 April 1991
DETAIL SPECIFICATION
CONNECTORS, PLUG AND RECEPTACLE, ELECTRIC,
RECTANGULAR, HIGH DENSITY, POLARIZATION CENTER JACKSCREW
GENERAL SPECIFICATION FOR
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This detail specification covers the general requirements for rectangular electrical connectors, with size 22,
nonremovable, solder type contacts, and rear removable crimp type contacts, environment resistant and non-environment, intended
for use in electronic and electrical equipment (see 6.1 for restrictions on intended use and application).
1.2 Classification.
1.2.1 Classes:
G
-
General purpose, nonmagnetic, high density, size 22, rear release, crimp removable contacts.
P
-
Environmental resisting, potting type, nonmagnetic, high density, size 22, rear release, crimp removable contacts.
E
-
Environmental resisting, nonmagnetic, high density, size 22, rear release, crimp removable contacts.
S
-
Solder termination, general purpose, high density, nonremovable, size 22 contacts.
SE
-
Solder termination, interfacial seal, high density, nonremovable, size 22 contacts.
1.2.2 Part or Identifying Number (PIN). The PIN shall consist of the letter "M", the basic number of the specification sheet, and
an assigned dash number as shown in the following example:
-1
N
M
28804/1
Military designator
Specification
Dash
Polarization
sheet number
number
letter
(see 3.5.5)
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3 and 4 of this specification. This section does not
include documents cited in other sections of this specification or recommended for additional information or as examples. While
every effort has been made to ensure the completeness of this list, document users are cautioned that they must meet all specified
requirements documents cited in sections 3 and 4 of this specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and handbooks form a part of this
document to the extent specified herein. Unless otherwise specified, the issues of these documents are those listed in the issue of
the Department of Defense Index of Specifications and Standards (DoDISS) and supplement thereto, cited in the solicitation (see
6.2).
Beneficial comments (recommendations, additions, deletions) and any pertinent data which may be of use in
improving this document should be addressed to: Defense Supply Center Columbus, ATTN: DSCC-VAI,
3990 East Broad Street, Columbus, OH 43216-5000, by using the Standardization Document Improvement
Proposal (DD Form 1426) appearing at the end of this document or by letter.
AMSC N/A
FSC 5935
