MIL-DTL-3650B
4. VERIFICATION
4.1 Classification of inspections. The inspection requirements specified herein are classified as
follows:
a. Component-materials inspection (see 4.2).
b. Conformance inspection (see 4.3).
4.2 Component-materials inspection. Component-materials inspection shall consist of verification that
the component materials listed in table I, used in fabricating the connectors, are in accordance with the
applicable referenced specifications or requirements prior to such fabrication.
TABLE I. Component-materials inspection.
Component
Requirement
Applicable
material
paragraph
specification
ASTM B16, ASTM B36, ASTM B121 or ASTM B124
3.2.1
Brass
3.2.2
Copper beryllium
ASTM B194, ASTM B196 or ASTM B197
Insulating and sealing compound
3.2.3
SAE-AS8660
3.2.4
ASTM B139
Phosphor bronze
Dielectric materials:
3.2.5.1
ASTM D4976
Polyethylene
3.2.5.2
Polystyrene
L-P-516
3.2.6
A-A-59588
Silicone rubber
3.2.7
ASTM D2000
Synthetic rubber
3.2.8
QQ-B-654
Silver solder
O-F-499
3.2.8.1
Flux
J-STD-006
3.2.9
Soft solder
4.3 Conformance inspection.
4.3.1 Inspection conditions. Unless otherwise specified herein, all inspections shall be made at room
ambient temperature, relative humidity, and pressure.
4.3.1.1 Inspection lot. An inspection lot, shall consist of all the connectors of the same type
designation, produced under essentially the same conditions, and offered for inspection at one time.
However, at the discretion of the Government, an inspection lot may be composed of connectors
representing a number of contracts or orders and may consist of different types of connectors in any of
the following combinations:
a. Types UG-155/U and UG-287/U, latest versions.
b. Types UG-208/Uand UG-216/U, latest versions.
In combination lots, the number of samples of each different type of connector taken from the lot shall be
in approximately the same proportion as the number of each type making up the lot.
4.3.1.2 Resubmitted lots. If an inspection lot is rejected, the supplier may replace it with a new lot,
rework it to correct the defects, or screen out the defective units, and submit it again for acceptance
inspection. Resubmitted lots shall be kept separate from new lots and shall be clearly identified as
resubmitted lots.
