MIL-DTL-38999/31E
mm
Inches
mm
Inches
mm
Inches
mm
Inches
mm
Inches
0.8
.03
7.11
.28
15.01
.59
46.0
1.81
76.2
3.0
6.3
.25
9.5
.37
42.5
1.67
63.5
2.50
NOTES:
1. Dimensions are in millimeters. Inch equivalents in parentheses are given for information only.
2. Polarizing position N is shown.
3. EMI grounding feature required on this connector.
4. Inactive for new design. The Government will not stock, store or issue this configuration.
5. Only insert arrangements 25-11 and 25-20 of MIL-STD-1560 apply.
FIGURE 2. Plug, classes W and X, type 2.
2
