MIL-DTL-38999/31E
mm
Inches
mm Inches
mm
Inches
mm
Inches
0.8
.03
9.5
.37
31.0
1.22
51.0
2.01
6.3
.25
15.01
.59
33.3
1.31
53.4
2.10
7.11
.28
19.0
.75
42.5
1.67
63.5
2.50
NOTES:
1. Dimensions are in millimeters. Inch equivalents in parentheses are given for information only.
2. Polarization position N is shown.
3. EMI grounding feature required on this connector.
4. The Government may stock, store, and issue this configuration.
FIGURE 5. Plug, classes J and M, type 5.
5
