MIL-DTL-38999-31 Connectors, Electrical, Circular, Threaded, Plug, Lanyard Release, Fail-Safe, Removable Crimp Contacts, Pins, Shell Size 25, Series Iii, Metric

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10

MIL-DTL-38999/31E

Inches

0.8

.03

7.11

.28

15.01

.59

46.1

1.81

53.6

2.11

6.3

.25

9.5

.37

19.0

.75

53.4

2.10

63.5

2.50

NOTES:

1. Dimensions are in millimeters. Inch equivalents in parentheses are given for information only.

2. Polarization position N is shown.

3. EMI grounding feature required on this connector.

4. The Government may stock, store and issue this configuration.

FIGURE 3. Plug, classes J and M, type 3.
