MIL-DTL-641F

Inches

.0003

.008

.02

.190

4.83

.50

12.7

1.209

30.71

.001

.03

.033

.84

.208

5.28

.600

15.24

1.25

31.8

.002

.05

.065

1.65

.244

6.20

.625

15.88

.003

.08

.104

2.64

.250

6.35

.650

16.51

.005

.13

.125

3.18

.275

6.98

.855

21.72

.010

.28

.128

3.25

.312

7.92

1.000

25.40

NOTES:

1. Dimensions are in inches.

2. Metric equivalents are given for information only.

3. Finger shall be hardened to Rockwell C 60-62, polished, and then hard-chromium plated to .0003 (.008 mm)

maximum thickness.

4. All dimensions before plating.

5. Concentricity shall be .002 (.05 mm) total indicator reading on finger diameter A.

FIGURE 6. Test plug TP327.
