MIL-DTL-641F

Inches

.0003

.008

.172

4.37

.001

.03

.188

4.78

.003

.08

.250

6.35

.005

.13

.281

7.14

.025

.64

.730

18.54

.125

3.18

NOTES:

1. Dimensions are in inches.

2. Metric equivalents are given for information only.

3. Finger shall be hardened to Rockwell C 60-62, polished, and then hard-chromium plated to .0003 (.008 mm)

maximum thickness.

4. All dimensions before plating.

5. Concentricity shall be .002 (.05 mm) total indicator reading on finger diameter A.

FIGURE 7. Test plug TP384.
