MIL-DTL-83503/25C
Inches
mm
Inches
mm Inches
mm Inches mm
4.3
.17
2.0
.08
0.76
.030
0.08
.003
4.52
2.26 .178
.089
0.81
.032
0.13
.005
4.83
2.54 .190
.100
0.86
.034
0.15
.006
6.10
2.67 .240
.105
0.89
.035
0.25
.010
6.35
2.95 .250
.116
1.07
.042
0.3
.01
7.37
3.18 .290
.125
1.14
.045
0.30
.012
7.9
3.61 .31
.142
1.3
.05
0.38
.015
8.94
.352
3.8
.15
1.27
.050
0.51
.020
9.14
3.86 .360
.152
1.52
.060
0.64
.025
33.0
4.06 1.3
.16
1.57
.062
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified tolerances are ± .005 inch (0.13 mm) for three place decimals and
± .01 inch (0.3 mm) for two place decimals.
4. For 10 and 14 position connectors the polarizing feature on this end is non-existent.
5. Two thread cutting screws, No. 4-24 (1/4 inch (6.35 mm) length) type BG are provided.
6. Pin length for printed wiring board (PWB) shall be as follows:
PWB thickness
Pin length
Pin length
inch
inch
inch
(mm)
(mm)
(mm)
min
max
.062 (1.57)
.089 (2.26)
.116 (2.95)
.125 (3.18)
.152 (3.86)
.178 (4.52)
7. Solderless wrappost, pin length shall be .610 ± .015 inch (15.49 ±0.38 mm).
FIGURE 1. Dimensions and configuration - Continued.
