MIL-DTL-83503/25C
Inches
mm
.0012
0.030
.0015
0.038
.003
0.076
A
B
C
Parallelism
Straightness
inch
inch
Inch
inch
Inch/inch
(mm)
(mm)
(mm)
(mm)
.025 (0.64) nominal .025 (0.64) nominal .0355 (0.902) max
.002
.005
.022 (0.56) min
.022 (0.56) min
.0325 (0.823) min
(0.05)
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. If the tip of the wrappost terminates in a bevel, the apex of the bevel shall be flat, with no side of the
flat exceeding .015 inch (0.38 mm).
FIGURE 3. Wrappost geometry.
7
