MIL-PRF-39012/1H
TABLE II. Group qualification Continued. 1/
1/
If a connector manufacturer produces a connector which meets all the requirements for two or more
connector PIN's (within the same series), the manufacturer may receive qualification approval for two
or more connector PIN's by qualifying the one connector. It is not necessary that such connectors be
in the same group. Each connector, however, must be marked with its own appropriate PIN. For
group qualification, the connectors must be of similar design and be of the same materials and
plating.
2/
For qualification retention, where more than one part is listed in a group in this column, data may be
supplied on any of those parts in order to retain qualification for those parts in the corresponding
right-hand column. The part does not necessarily have to be the part initially qualified.
TABLE III. CATEGORY B NONFIELD REPLACEABLE (SPECIAL TOOLS MAY BE REQUIRED). 1/
NOT FOR ARMY, NAVY OR AIR FORCE USE. FOR OEM USE ONLY
PIN 2/
Applicable cable 3/
Dimensions
Inches (millimeters)
M39012/01B
M17/
Maximum 9/
0006 4/
73-RG212 5/
162-00001
0007 4/
74-RG213 5/
0008 4/
75-RG214 5/
A
2.000(50.80)
0011 4/
65-RG165 5/ 6/
B
.827 (21.01)
0012 4/
86-00001
0013 4/
6-RG11 7/
62-RG144 5/ 6/ 7/
0014 4/
77-RG216 5/ 7/
0026 8/
W-RG6 6/ 7/
1/ For maintenance replacements for category B, see table V.
2/ For cross-reference of dash number to superseded PIN or type designation, see table IV.
3/ The latest version of each cable shall be applicable.
4/ Inactive for new design.
5/ Cable to be used when performing tests requiring cable except as in 6/ and 7/
6/ Cable to be used for the +200°C temperature cycling tests.
7/ These are not 50-ohm cables; therefore, when attached to the specified connectors, VSWR, RF
leakage, and insertion loss are not applicable.
8/ These connectors have captivated center contacts.
9/ Dimensions are in inches. Metric equivalents are given for information only.
12
