MIL-PRF-39012/1H
Basic crimp
Crimp die or
Ferrule no.
tool 2/
positioner
Dash no.
1/
A
B
C
M22520/5
M22520/5-
.438 ± .003
X501
1-50
61 or 25
.600 ± .015
.492 ± .003
.418 ± .003
Closure A
X502
1-51
.250 ± .003
.220 ± .003
-01
05, 11, 57
X503
1-52
.500 ± .015
.245 ± .003
.206 ± .003
Closure A or
X504
1-53
19 Closure B
1/ Ferrule numbers are for identification only.
2/ Class 2 tools may be used by OEM (see MIL-DTL-22520).
NOTES:
1. Dimensions are in inches.
2. Metric equivalent are given for information only.
3. Crimp tensile test shall be in accordance with SAE-AS39029.
4. Copyright notice: All information disclosed in these specification sheets which is or may be
copyrighted is reproduced herein with the express permission of the copyright owner.
5. Maximum break .003 inch (0.08 mm).
6. Color bands shall be positioned so that no coloring material enters the inspection hole.
FIGURE 3. Contact and ferrule dimensions for category D only Continued.
7
