MIL-PRF-39012/1H
TABLE I. Dash numbers, cross-reference, and dimensions Continued.
Dash number
Applicable cable
Dimensions
Inches
1/
M17/
(millimeters)
2/
maximum #
Category D Field replaceable Defined piece part 3/ 4/ 8/ 11/ 12/
Cable group XB
X501
127-RG393 5/
A
1.593 (40.48)
B
.827 (21.01)
Cable group XA
X502
65-RG165 5/
Cable group VIB
X503
1.516 (38.50)
A
60-RG142 6/
.827 (21.01)
B
128-RG400 5/
Cable group VIA
X504
111-RG303 5/
1/ For cross-reference of dash number to superseded Part or Identifying Part Number (PIN) or type designation,
see table IV.
2/ The latest version of each cable shall be applied.
3/ These connectors have captivated center contacts.
4/ Some of the cables in some cable groups are not 50 ohms; therefore, when attached to the specified
connectors, VSWR, RF leakage and insertion loss are not applicable. Refer to MIL-PRF-39012
appendix for cable groupings.
5/
Cable to be used when performing tests requiring cable except as in 4/ and 6/.
Cable to be used for the +200°C temperature cycling tests.
6/
7/
Armored cable.
8/
These connectors are assembled using the applicable crimp tool, to the specified cables stripped as
shown on figure 4.
9/
M22520/5-35 closure A or M22520/5-55 closure A.
10/
M22520/5-61.
11/
Complete connector assembly shall consist of a body, center contact, ferrule and assembly
instructions.
12/
Not to be used in army equipment.
13/
The superseded dash numbers are NOT acceptable for government use.
#
Dimensions are in inches. Metric equivalents are given for information only.
X
Denotes connector body plating material option. The only plating options allowable are Silver or Nickel over
brass in accordance with MIL-PRF-39012. Only connectors of the same materials shall be mated to avoid
dissimilar metal problems. CAUTION: A NICKEL PLATED BODY IS NOT FOR USE IN
APPLICATIONS WHERE PASSIVE INTERMODULATION GENERATION (PIM) MAY BE A
CONCERN (https://amphenolrf.com/simple/PIM%20Paper.pdf). Silver is the preferred plating
option.
5
