MIL-PRF-39012/16H
TABLE I. Dash numbers, cross reference, and dimensions Continued.
Inches (millimeters)
PIN 1/
Applicable cable 2/
Dimensions
maximum #
M39012/16-
M17/
Category C field replaceable (MIL-DTL-22520 crimp tool)
See note next to applicable cable for crimp die 3/ 8/
Cable group IV 11/
X016
54-RG122 6/
X017
Cable group VIIB 10/
A
1.500 (38.10)
90-RG71 6/ 7/
X222
Cable group IIA 12/
113-RG316 5/ 6/ 12/
Category D Field replaceable Defined piece part 3/ 8/ 13/ 14/
X501
Cable group IV
54-RG122 6/
X502
Cable group V
95-RG180 5/ 6/ 7/
1.500 (38.10)
A
X503
Cable group VIB
Cable group VIB
60-RG142 5/
128-RG400 6/
X504
Cable group VIA
111-RG303 5/ 6/
1/ For cross-reference of dash number to superseded PIN or designation, see table IV.
2/ The latest version of each cable shall be applicable.
3/ These connectors have captivated center contacts.
