MIL-PRF-39012/16H
Crimp die
Ferrule
A
B
Basic crimp
Dash number
or positioner
number 1/
± 0.003
± 0.003
tool 2/
M22520/5
-9 Closure A
X501
16-50
0.212
0.175
-5 or 41
X502
Closure B
M22520/5-01
X503
16-51
0.250
0.220
-5, -11, -57
Closure A or
X504
16-52
0.245
0.206
19 Closure B
1/ Contact numbers and ferrule numbers are for identification only.
2/ Class 2 tool may be used by OEM (see MIL-DTL-22520).
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Crimp tensile test shall be in accordance with SAE-AS39029.
4. Copyright notice: ALL information disclosed in these specification sheets which is or may be copyright
is reproduced herein with the express permission of the copyright owner.
5. .003 inch maximum break.
6. Color bands shall be positioned so that no coloring material enters the inspection hole.
FIGURE 3. Contact and ferrule dimensions for category D only Continued.
