MIL-PRF-39012/17H
TABLE I. Dash numbers, cross-reference, and dimensions Continued.
11/ M22520/5-41 closure B or M22520/5-05 closure 8.
M22520/5-09 closure A.
12/ M22520/5-35 closure B or M22520/5-03 closure A.
13/ Complete connector assembly shall consist of a body, center contact, ferrule and assembly
instructions.
14/ Not to be used in Army equipment.
#
Dimensions are in inches. Metric equivalents are given for information only.
X
Denotes connector body plating material option. The only plating options allowable are Silver or
Nickel over brass in accordance with MIL-PRF-39012. Only connectors of the same materials shall
be mated to avoid dissimilar metal problems. CAUTION: A NICKEL PLATED BODY IS NOT FOR
USE IN APPLICATIONS WHERE PASSIVE INTERMODULATION GENERATION (PIM) MAY BE A
option.
Crimp die or
Ferrule
A
B
Basic crimp
Dash
number
positioner
± 0.003 ± 0.003
tool 2/
number
1/
M22520/5
05, 41
X501
17-50
0.212
0.175
Closure B or
X502
9 Closure A
M22520/5-01
5, 11, 57
X503
17-51
0.250
0.220
Closure A or
X504
17-52
0.245
0.206
19 closure B
1/ Contact numbers and ferrule numbers are for identification only.
2/ Class 2 tool may be used by OEM (see MIL-DTL-22520).
FIGURE 3. Contact end ferrule dimensions for category D only.
.
6
