MIL-PRF-39012/17H
Inches
mm
Inches
mm
Inches
mm
Inches
mm
.001
0.03
.033
0.84
.145
3.68
.220
5.59
,002
0.05
.035
0.89
.175
4.45
.230
5.84
.003
0.08
.040
1.02
.183
4.65
.235
5.97
.005
0.13
.043
1.09
.206
5.23
.250
6.35
.015
0.38
.067
1.70
.210
5.33
.478
12.14
.017
0.43
.083
2.11
.212
5.38
.500
12.70
Color
Color
Crimp
band
band
A
Tensile
Basic crimp
Crimp die or
Contact No.
+0.001
pounds,
Dash No.
1/
tool 2/
positioner
-0.002
min. (N)
10 lbs.
X501
17-12
0.033
Orn
(44.48)
M22520/1-01
M22520/1-12
6 lbs.
X502
17-11
0.017
Blue
Green
(26.69)
X503
20 lbs.
17-10
0.043
M22520/1-01
M22520/1-12
Red
X504
(88.96)
1/ Contact numbers and ferrule numbers are for identification only.
2/ Class 2 tool may be used by OEM (see MIL-DTL-22520).
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Contact material shall be copper beryllium. Connectors supplied with phosphor bronze
contacts are acceptable for Government use until existing stock is purged. This elimination
of the contact material option shall take effect 1 year from the date of this specification.
4. Crimp tensile test shall be in accordance with SAE-AS39029.
5. Copyright notice: All information disclosed in these specification sheets which is or may be copyright
is reproduced herein with the express permission of the copyright owner.
6. .003 inch maximum break.
7. Color bands shall be positioned so that no coloring material enters the inspection hole.
FIGURE 3. Contact and ferrule dimensions for category D only Continued.
